6.2
Decoding of the microprocessor address space is accomplished with a
Programmable Logic Array [U110 (16L8)]. The Memory space allocation is
Address Device Part Number Function
$0000-$7FFF
U103
58258
Static RAM
$A000-$A007
U106
9914A
IEEE Controller
$A800-$A807
U105
6551
UART
$B000-$B00F
U104
65B22
VIA
$B800
U201
74HCT244
SW1 (S201)
$B801
U202
74HCT244
SW2 (S202)
$B802
U203
74HCT244
SW3 (S203)
$E000-$FFFF
U102
2764
Programmed EPROM
