ADAC-TB-8 Screw-Terminal Board Connections
The ADAC-TB-8 provides screw-terminal access to all of a ADAC/5500MF board’s analog and digital I/O
signals. The terminal board connects to the ADAC/5500MF via a 3-foot long 68-pin conductor expansion
cable, p/n CA-G55-ADAC. The terminal board accepts wire up to 14 AWG.
ADAC-TB-8
WARNING
Always turn the computer power OFF and unplug it before connecting or disconnecting a screw
terminal panel or a cable to the PCI card. Failure to do so could result in electric shock, or
equipment damage.
