Depending on the system, the extended
zoom mode is supported for lens focal
lengths of 28 mm or more (35-mm format).
The camera must be equipped with a CPU
lens and be able to transfer data on the lens
focal length to the flash unit.
11.4.2 SPOT zoom mode
In spot zoom mode, the zoom position of the
reflector is increased by one level compared
to the focal length of the camera lens. The
resulting reduced illumination provides
centre-weighted illumination or alternatively
shadowy edge lighting.
Example:
The focal length of the camera lens is 50 mm.
The spot zoom mode sets a 70 mm reflector
position on the flash unit. However, 50 mm
continues to be shown on the display.
Setting procedure
• Press the ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select .
• Press the sensor button on the
touch display.
• Press the sensor button on the
touch display.
The setting is adopted immediately.
After activation of spot zoom mode, "SP"
appears in the INFO menu.
Depending on the system, the spot zoom
mode is supported for lens focal lengths of
24 - 180 mm or more (35-mm format).
The camera must be equipped with a CPU
lens and be able to transfer data on the lens
focal length to the flash unit.
D
OPTION
ZOOM MODE
ZOOM MODE
SPOT
194
k
ZOOMMODE
O
EXTENDED
STANDARD
SPOT
OPTION
OPTION
O
q p
ZOOM SIZE
ZOOM MODE
STANDBY
