REMKO PWL 101 HK - Manual (Page 19)

19
Type PWL 301-HK PWL 302-HK PWL 303-HK
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection 400/3~N
Frequency Hz 50
Power consumption kW 0.36/0.22
Nominal current A 0.84/0.46
Air capacity m³/h 4300 2650 4150 2400 3900 1710
Sound pressure level 1) dB (A) 66 59 66 59 68 61
Hydraulic connection Inch R 1“ R 1“ R 1“
Water volume l 1.1 2.0 3.3
Condensate
max
. l/h 3.0 2.7 4.2 4.1 9.5 6.7
Weight kg 43 46 48
PKW coolant
t
L1/r.H.
°C/%
kW
t
L2/r.H.
°C/%
kW
t
L2/r.H.
°C/%
kW
t
L2/r.H.
°C/%
kW
t
L2/r.H.
°C/%
kW
t
L2/r.H.
°C/%
kW
t
L2/r.H.
°C/%
4 / 8 °C
24/60 6.9 21/70 5.5 20/72 8.9 18/71 8.4 17/81 17.8 15/84 10.9 15/82
26/50 7.0 22/61 5.5 21/63 11.1 19/70 8.5 18/74 18.0 16/79 11.0 13/86
28/45 7.7 23/57 6.0 23/59 12.1 20/67 9.2 19/71 19.3 17/76 11.8 13/83
30/40 8.2 25/52 6.5 24/55 12.9 22/63 9.9 20/68 20.4 18/73 12.5 14/81
32/40 9.6 26/52 7.6 25/55 15.1 23/63 11.5 21/68 23.5 19/73 14.3 15/82
6 / 10 °C
24/60 5.6 21/70 4.4 20/71 8.9 19/77 6.8 18/80 15.0 16/84 9.3 14/89
26/50 5.7 22/61 4.5 22/63 9.0 20/71 6.9 19/74 15.1 17/78 9.3 14/85
28/45 6.3 24/57 5.0 23/59 10.0 21/67 7.7 20/71 16.5 18/76 10.1 15/83
30/40 6.8 25/52 5.4 24/55 10.8 22/63 8.3 20/68 17.6 18/73 10.8 15/81
32/40 8.3 27/52 6.5 26/55 13.0 23/63 10.0 22/68 29.1 19/73 12.7 16/81
8 / 14 °C
24/60 3.0 22/68 2.3 21/70 8.4 17/81 3.6 19/79 9.4 18/84 6.0 16/89
26/50 3.7 23/58 2.8 23/61 8.5 18/74 4.4 20/70 9.9 18/80 6.1 16/85
28/45 4.3 25/54 3.3 24/56 9.2 19/71 5.2 21/67 11.3 19/77 7.0 17/83
30/40 5.0 26/49 3.8 26/52 9.9 20/68 6.0 22/63 12.8 20/73 7.7 17/81
32/40 5.7 28/51 4.3 27/53 11.5 21/68 6.7 23/66 15.0 21/73 9.5 18/81
10 / 16 °C
24/60 2.4 22/66 1.8 22/68 6.8 18/80 2.9 20/75 7.0 19/84 4.0 17/89
26/50 3.0 24/57 2.3 23/59 6.9 19/74 3.7 21/66 8.5 19/74 4.9 17/85
28/45 3.7 25/53 2.8 25/55 7.7 20/71 4.5 22/63 9.9 20/72 5.7 18/83
30/40 4.4 27/48 3.3 26/50 8.3 20/68 5.2 23/59 11.3 21/68 6.5 18/80
32/40 5.1 28/49 3.8 28/52 10.0 22/68 6.0 24/63 12.8 22/72 7.6 19/81
12 / 18 °C
24/60 1.7 23/65 1.3 23/66 3.6 19/79 2.2 21/71 5.5 20/78 3.2 18/85
26/50 2.4 24/55 1.8 24/57 4.4 20/70 3.0 22/63 7.0 21/69 4.1 19/78
28/45 3.1 26/51 2.3 25/53 5.2 21/67 3.7 23/60 8.5 21/69 4.9 19/76
30/40 3.7 27/47 2.9 27/40 6.0 22/63 4.5 24/56 9.9 22/63 5.7 20/73
32/40 4.4 29/48 3.4 28/50 6.7 23/66 5.3 25/59 11.3 23/68 6.5 20/80
We reserve the right to make dimensional and design changes in the interest of technical advances.
PWL 301-303 - Cooling • Rating tables • Technical Data
t
L1
= air inlet temperature/t
L2
= air outlet temperature
1) LpA 1m, noise measurement DIN 45635 - 01 - CATEGORY 3
