OPERATING PROCEDURES
WARNING! For the safe operation of this machine
follow the instructions given in this booklet and
the training given by your supervisor. Failure to
do so can result in personal injury and/or damage
to machine and property!
DO NOT OPERATE MACHINE IN AN EXPLOSIVE EN-
VIRONMENT!
NEVER USE THIS MACHINE TO PICK UP VOLATILE
OR EXPLOSIVE MATERIALS!
The model shown in this manual is intended for com-
mercial use.
PREPARATION
To prepare the machine for operation, make sure it is of
correct voltage and properly assembled. If in doubt,
ask your supervisor.
§ If the vacuum is in its upright position (page 6), raise
the handle while supporting the vacuum, then
slowly lower the vacuum to the floor.
§ Properly install the filter bag in the vacuum:
Lift the cover from the machine. The filter bag inlet
is designed with a rubber gasket that fits securely
over the bag adapter (page 7) in the cover. First
push the filter bag inlet over the adapter on the cover.
Then from the outside of the cover reach inside the
adapter and push the gasket on the rest of the way.
Replace the filter bag when full.
OPERATION
1. Plug the machine’s power cable into a prop-
erly grounded outlet (see Grounding Instructions).
2. The foot pedal should be raised to the “BRUSH”
position (page 8) for wide area vacuuming.
3. Adjust the brush height with the lever located on
the rear of the machine near the floor (page 8).
4. Turn the vacuum switch ON (rocker switch on
operator’s right, page 7).
5. Turn the brush switch ON (rocker switch on
operator’s left, page 7) and begin vacuuming.
OPERATION WITH TOOLS
Three on-board tools are available for the vacuum: the
dusting tool, crevice tool and turbo tool (page 6). Twenty
(20) feet of hose is provided which allows access to
rooms without moving the machine.
1. The brush and vacuum switches should be
turned OFF.
2. Depress the foot pedal to the “ACCESSORY”
position.
3. Remove the rigid portion of the accessory hose
from its’ storage area in the handle and attach the
tool of choice.
4. Turn the vacuum switch ON and begin.
Note: The vacuum switch should be OFF when switch-
ing the foot pedal between the accessory and the brush
positions.
MAINTENANCE
ALWAYS turn the brush and vacuum motor switches
OFF and UNPLUG the power cord from the electri-
cal outlet before doing any clean-up or repairs,
and when the machine is left unattended.
AFTER EACH USE:
1. Vacuum filter bag: If the bag is full or damaged
install a new one.
Filter Bag, 10 Pack – Part Number 650602
Cloth Bag (optional) – Part Number 650601
2. Power cord and plug: Check for cuts or nicks; if
damaged, have the cord replaced at a factory au-
thorized service center.
3. Casters and Wheels: Remove any strings or de-
bris that may restrict the free movement of the cast-
ers.
4. Tools: Inspect the tools to ensure there is no ob-
struction of airflow. Remove any debris found.
5. Brush: Remove any strings or debris. Replace if
becomes worn or damaged.
Storage: The handle may be folded down and the
machine stored upright to reduce storage space
requirements. Store the machine in a clean dry area.
4
