Page 9
Hoses and Hand Tool
Drawing # Item ID Item Description Qty Needed
1 . 10-0501 4" Stainless Steel Uph. Tool 1.00
2 . 10-0463 Black Slip Hose Cuff - Spotter 2.00
3 . 50-1008 15Ft. Vacuum Hose 1-1/4" 1.00
4 . 10-0868 1/4" Female QD for Sniper 1.00
5 . 80-8007 1/4" x 15ft. Extractor Hose 1.00
6 . 10-0388 Velcro Strap 1.00
7 . 10-0870 1/4" Male QD 1.00
8 . 10-0507 8" Black Hose for SS Hand Tool 1.00
9 . 10-0506 Valve clamp for SS Hand Tool 1.00
10 . 10-0504 Valve for Stainless Hand Tool 1.00
11 . 10-0502 Jet for Stainless Hand Tool 1.00
3-Gallon Carpet Spot Extractor
100 CFM / 804 Watt Motor
™
