FRONT PANEL DESCRIPTION
(1) Mains switch: Used to switch on and off the unit by switching the mains voltage.
(2) LED indicator: Lights blue indicating that the CD-player is on stand-by mode. Switched off
when the CD-player is in operation and LCD display is lit.
(3) LCD display: main display displaying most of the function performed.
(4-8) Direct access buttons to stored stations
(9) FM/AM: Switches between FM and AM.
(10) Autotune: Press this button once and the tuner will start to automatically tuning and
store all available stations.
(12) Memory: After manually tuning in station, press this button once and the tuned in
channel will be stored on the current preset.
(11) Preset -: Changes down in presets.
(13) Preset +: Changes up in presets.
(14) ST/Mono: Changes between stereo and mono on the FM band.
(15) Reset: Resets the tuner.
(16) Tuning: Turn this button clockwise to tune up in frequency, and counter clockwice to
tune down in frequency.
REAR PANEL DESCRIPTION
Stereo Output: Analogue stereo output. For connection to stereo amplifier with analogue input.
Antenna: For connection of FM or AM antenna or for the communal or cable antenna system.
AC input: For connection of mains voltage. Make sure that the plug has been correctly
inserted, and that the voltage corresponds to the text printed on the back panel of the cabinet.
