Raptor DL-Lite X11R6.1 for AIX Installation Manual
2-2
NOTE: Remember which cables go to which connectors. You may
want to label the cables and connectors before disconnecting them.
Step 1:
Shutdown the system and turn the power OFF.
Remove the system’s cover, find an available PCI
Local Bus slot, and remove the bracket and screw.
Ground yourself by touching the metal part on the
case.
Step 2:
Install the Raptor card firmly into the PCI Local
Bus slot. Take care to press it evenly and snugly
into the slot. Once you are certain the card is
installed properly in the slot, secure it with the
bracket screw.
Step 3:
Secure the system’s cover, attach any previously
removed cables.
Step 4:
Connect the Dual Link DVI cable from the Apple
HD panel to the Raptor DL-Lite card.
The Raptor card is now installed and the system is ready for
software installation. Refer to Chapter 3 for installing the Raptor
DL-Lite X11R6.1 for AIX software.
