All Power APG3002S - Manual (Page 34)

3500W Generator
34
APA Part No. Description Part No.
B
APG3012-B-01-JD CRANK CASE JF200-B-01
APG3012-B-02-JD OIL LEVEL SWITCH ASSY. JF168-B-02
APG3012-B-03-JD GOVERNOR GEAR ASSY. JF168-B-03
APG3012-B-04-JD SLIDER SHAFT JF168-B-02
APG3012-B-05-JD GOVERNOR ARM SHAFT JF168-B-02
APG3012-B-06-JD LOCK PIN (8mm) JF168-B-04
APG3012-B-07-JD WASHER JF168-B-05
APG3012-B-08-JD DRAIN PLUG BOLT JF168-B-06
APG3012-B-09-JD THRUST WASHER (6mm) JF168-B-07
APG3012-B-10-JD DRAIN PLUG WASHER (10.2mm) JF168-B-08
APG3012-B-11-JD SLIDER WASHER JF168-B-09
APG3012-B-12-JD BALL BEARING (6205) JF168-B-10
JF168-B-11
APG3012-B-14-JD OIL ALERT JF168-B-12
APG3012-B-15-JD FLANGE NUT (M10) and O-RING JF168-B-13
APG3012-B-16-JD GOVERNOR SLIDER JF168-B-13
APG3012-B-17-JD FLANGE BOLT (M6X12) JF168-B-13
Cylinder barrel
