Page 17
HYDROSTAT LINKAGE ASSEMBLY PARTS
MODEL TLB 20K-25K
A-4D
NO REQ’D PART NO
DESCRIPTION
1
1
92T070
CENTER BEARING PIVOT WELDMENT
2
1
HD045
5/32 X 1-1/2 COTTER PIN
3
1
92T055B
BUSHING
4
2
712572
OFFSET YOKE, 3/8 - 24 NF (AFTER SN 9707T23)
**
5/16 SPLIT LOCKWASHER (BEFORE SN 9707T23)
5
2
HN080
3/8 -16 NC TOP LOCK NUT (AFTER SN 9707T23)
**
5/16 -24 NF HEX NUT (BEFORE SN 9707T23)
6
2
**
3/8 SAE FLAT WASHER (AFTER SN 9707T23)
7
1
921168
LINKAGE ARM, HYDROSTAT, SQUARE BUSHING
8
1
920218
CAM FOLLOWER
9
1
401257
1/4 - 28 NF 90* GREASE ZERK
10
1
92T069
CENTER BEARING MOUNT PLATE WELDMENT
11
1
**
5/8 SPLIT LOCKWASHER
12
1
**
5/8 -18 NF HEX NUT
13
2
**
5/16 -24 NIF NYLON INSERT NUT
14
2
**
5/16 FLAT WASHER
15
2
**
5/16 - 18 NC HEX NUT
16
1
**
5/16 - 18 NC x 1" GRADE 5 BOLT
17
2
**
3/8 -16 NC x 2" GRADE 8 BOLT ( AFTER SN 9707T23)
920174
SPHERICAL ROD END - RIGHT HAND (BEFORE SN 9707T23)
18
2
3/8 - 24 NF HEX NUT (AFTER SN 9707T23)
19
1
92T155
3/8 LINK ROD (AFTER 9707T23)
92T082
LINK ROD (BEFORE 9707T23)
20
2
**
3/8 - 16 NC x 2" GRADE 5 BOLT (AFTER SN 9706T19)
21
2
**
3/8 SPLIT LOCKWASHER
22
2
**
5/16 HARDENED STEEL FLAT WASHER (AFTER SN 9706T1
23
1
92T160
RIGHT FOOT PEDAL F/R LINKAGE ARM
24
1
**
5/16 - 18 NC NYLON INSERT NUT
25
1
HD068
5/16 - 18 NC x 3" EYE BOLT
26
1
920236
SPRING, PEDAL RETURN
27
1
**
5/16 - 24 NF HEX NUT
28
1
92T048
CENTER BEARING PLATE
LEGEND: NS = Not Shown
** = Purchase locally
