59
CopperHead 3050
User Guide
The BASE Rx/DIM accesses the Camera Unit dimming function. To change the brightness of
the Camera Unit LEDs, push and hold the BASE Rx/DIM selector (this may take a few
moments). The dimming is cyclical - it will change from bright to dim, and then dim to
bright).
TEMP Repeats that the display is in the TEMP mode
61C Temperature display in Centigrade for Camera Unit main circuit board
DIAGNOSTIC MODE Power (POWR)
A Quick push of the BASE Rx/DIM Selector advances to the POWR mode
LBUS Indicates that the LBUS controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
UBUS Indicates that the UBUS controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
OBOX Indicates that the Audio Interface Box controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
BASE Indicates that main Camera Unit controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
DIAGNOSTIC MODE Microcontroller Board Revision Version (REV)
A Quick push of the BASE Rx/DIM Selector advances to the REV mode. This mode displays the
microcontroller firmware revision of every board in the Camera Unit that has a microcontroller.
Note: the REV versions is current as of August 1, 2010. Your system may have different REV versions
REV Indicates that mode is REV
OBOX Indicates the OBOX microcontroller board is revision is being queried
REVA Indicates that the REV for the Audio Interface Box board is REVA
REV Indicates that mode is REV
BASE Indicates the BASE microcontroller board is revision is being queried
REVA Indicates that the REV for the BASE Camera Unit controller board is REVA
REV Indicates that mode is REV
UBUS Indicates the UBUS microcontroller board is revision is being queried
REVA Indicates that the REV for the UBUS board is REVA
Display Description
<O0> Indicates maximum brightness with this readout
<--> Indicates minimum brightness with this readout
Readout Camera Unit Digital Display Activity Explanation
