Edius hd / sd + hdbx-1000h / s – Grass Valley EDIUS 5 User Manual
Page 61
H
ard
w
are S
pe
cifi
ca
tio
ns
EDIUS HD / SD + HDBX-1000H / S
Video
input
HD-SDI*
1 route BNC x 2
SMPTE 292M
HD-SDI IN
+ ACTIVE
THROUGH
SD-SDI
1 route BNC x 2
SMPTE 259M-C
SD-SDI IN
+ ACTIVE
THROUGH
Component 1 route BNC x 3
Betacam,
SMPTE / EBU-
N10
-
S-VIDEO
1 route S terminal x 1 -
-
Composite 2 routes BNC x 2
NTSC:
SMPTE170M,
PAL: ITU-
RBT.470
-
Video
output
HD-SDI*
2 routes BNC x 2
SMPTE 292M
-
SD-SDI
2 routes BNC x 2
SMPTE 259M-C
-
HD
component*
1 route BNC x 3
SMPTE 274M
-
Component 1 route BNC x 3
Betacam,
SMPTE / EBU-
N10
-
S-VIDEO
1 route S terminal x 1
-
-
Composite 2 routes BNC x 2
NTSC:
SMPTE170M,
PAL: ITU-R
BT.470
-
D terminal 1 route D terminal x 1
-
-
Audio
input
HD-SDI*
-
-
SMPTE 299M
Embedded
audio
SD-SDI
-
-
SMPTE 272M-A
Embedded
audio
AES/EBU
4 routes BNC x 4
AES3(AES-3id)
ch 1/2, ch 3/4,
ch5/6, ch7/8
Analog
balanced
audio
4 routes XLR3 pin x 4
-
600 ohm
terminal,
+4dBm
*Available
to switch
input level /
headroom
