30
Specifications
Kaleido-IP Display Outputs
The Kaleido-IP supports two independently configurable and operable progressive scan
display outputs.
Kaleido-IP X300 Frame
Kaleido-IP X100 Frame
Dolby Digital AC-3 (optional)
Dolby Digital Plus (DD+) (optional)
AAC Audio (optional)
AUDIO DECODERS (continued)
Connectors HDMI or DisplayPort
Standard DisplayPort 1.1a
HDMI 1.3a
Resolution Up to 1920 × 1200 @ 60 Hz (all progressive scan)
Height 89 mm (3.5 in) 2RU
Width 437 mm (17.2 in)
Depth 648 mm (25.5 in)
Weight 23.6 kg (52 lbs)
Power supply 700 W (1+1) hot-swappable, redundant power supply, 10-4 amp
Nominal power 400 W
AC 100-240 V, 60-50 Hz
Operating temperature 10-35 °C (50-95 °F)
Max. storage humidity 90% RH non-condensing
Max. functional humidity 65% RH non-condensing
Height 43 mm (1.7 in) 1 RU
Width 437 mm (17.2 in)
Depth 508 mm (19.98 in)
Weight 15 kg (33 lbs)
Power supply 400 W (1+1) hot-swappable, redundant power supply, 6-3 amp
Nominal power 151 W
AC 100-240 V, 60-50 Hz
Operating temperature 10-35 °C (50-95 °F)
