Menu structure | Menu structure
5-3
The main functions avalable in these menus are shown in the following tables. The
functions available depend on user level and camera configuration.
Table 5-1. Viewfinder menu
Main menu items
Purpose
VF mon
video signal in viewfinder
VF Contour
contours in viewfinder signal
Zebra
overexposure indication
Centre Cross
indication on or off
Safe Area
indication on or off
Audio Bar
indicator on or off
Iris Indicator
on/off
Focus Indicator
on/off
Zoom Indicator
on/off
Box downright
information box
4:3 Area
aspect ratio guides
Indicator White
display text intensity
Indicator Black
display text contrast
Display
viewfinder display duration
Menu Time
menu display duration
Info Time
information display duration
Rotary Speed
rotary control sensitivity
Box downleft
information box SuperXpander
Overscan
on/off and blanking bar style
Table 5-2. Lens menu items
Main menu items
Purpose
Lens Type
standard or wide angle lens
Auto Iris
on/off
Peak/Average
auto iris values
Auto Iris Setpoint
auto iris setpoint value
Mom. Iris Setpoint
momentary iris setpoint value
Manufacturer
Angenieux, Canon, Fuji, other
RE iris comp.
set range extender iris compensation on or off
Extended iris
gain, exposure, iris values
VTR Switch
select toggle or momentary
Handgrip zoom
select speed and curve for zoom control
