Installation Requirements SMA Technologie AG
Page 14 SBTLHCMS-IEN080411 Installation Guide
When choosing the installation site, be sure to note the following:
When choosing the installation location, ensure there is enough space for heat to dissi-
pate! Under normal conditions, the following guidelines should be followed to provide
enough clearance around the inverter.
In domestic installations, the unit should not be mounted
on plasterboard walls or similar as otherwise audible vi-
brations are likely to result.
We recommend securing the unit to a solid surface.
The Sunny Boy makes noises when in use which can, in
the domestic setting, be seen as a nuisance.
Caution: high voltage!
Unintentionally pulling out the DC plug connector under load can damage
the plug and result in bodily injury or death! Install the Sunny Boy in such
a way that it is not possible (e.g. for children) to unplug the DC plug con-
nector unintentionally.
Caution: risk of burns!
The temperature of individual parts of the enclosure - in particular the tem-
perature of the heatsink and the components within the Sunny Boy - can
reach more than 60 °C. Touching could result in burns!
Warning!
Do not install the Sunny Boy
•
on flammable construction materials,
• in areas where highly flammable materials are stored,
• in potentially explosive areas!
Minimum Clearance
Sides 20 cm
Top 20 cm
Underneath 50 cm
Front 5 cm
