Page 50: Appendix e, Driver installation
45
Driver Installation
Appendix E
Network Application Platforms
Linux
Follow these instructions when installing the Intel®
LAN controller base driver for the in Red Hat® and Linux
operating system.
Insert the motherboard/system support CD to the
1.
optical drive and mount the optional drive in the Linux
platform.
Copy the base driver tar file from the motherboard/
2.
system support CD to the directory of your local hard
disk. The Intel® LAN driver for Linux OS is located in the
following directory:
\Driver\LAN_Driver\PRO1000\LINUX. The name format
of driver file is “e1000-<Version>.tar.gz”. For example:
the file name of driver version 7.0.38 is “e1000-7.0.38.
tar.gz”.
Untar/unzip the archive, where <x.x.x> is the version
3.
number for the driver tar file:
tar zxf e1000-<x.x.x>.tar.gz
Change to the driver src directory on your system,
4.
where <x.x.x> is the version number for the driver tar:
cd e1000-<x.x.x>/src/
Compile the driver module by typing the following
5.
command:
make install
The binary will be installed as:
6.
/lib/modules/<kernel_version>/kernel/drivers/net/
e1000.o
The install locations listed above are the default
locations. They might not be correct for certain Linux
distributions.
Assign an IP address to the interface by entering the
7.
following, where <x> is the interface number:
ifconfig eth<x> <IP_address>
Verify that the interface works. Enter the following,
8.
where <IP_address> is the IP address for another
machine on the same subnet as the interface that is
being tested:
ping <IP_address>
Note: For LAN driver installation on other operating
systems, refer to the Intel® Gigabit Desktop Adapter
Guide which comes along with driver installation
program.
VGA Driver Installation
This section provides the instructions on how to install
VGA adapter drivers.
Windows Operating systems
Restart the computer, and then log on with
1.
Administrator privileges.
Insert the Drivers and User’s Manual CD to the optical
2.
drive.
Browse the contents of the support CD under the
3.
directory: \ Driver\VGA_Driver.
You may need to install the drivers manually if there
4.
is no available executable program for installing the
drivers automatically.
To install the drivers manually, use the Found New
5.
Hardware wizard of the Windows.
During the steps make sure that you choose to install
6.
the hardware by manually selecting the drivers that
you wish to install. When this option appears, you
should select the directory containing the drivers for
the VGA adapter.
