POWER SOURCE
This unit operates on 8 X ‘C’ (UM-2) size batteries or from AC220V/60Hz line power supply.
A. DC POWER OPERATION
1.
Open the Battery Door (#18).
2. Insert 8 “C” (UM-2) size batteries (not included) according to the polarity diagram on the back cabinet.
3. Close the Battery Door (#18).
IMPORTANT: Be sure that the batteries are installed correctly. Wrong polarity may damage the unit.
Note: For better performance and longer operating time, we recommend the use of alkaline-type batteries.
(a) Do not mix old and new batteries.
(b) Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
If the unit is not to be used for an extended period of time, remove the battery. Old or leaking battery can
cause damage to the unit and may void the warranty.
B. AC OPERATION
1. Connect the included AC Power Cord to the AC Mains
(#17) on the back of the unit.
2. Connect the other end of the AC Power Cord to a wall outlet with AC220V/60Hz power supply.
CD PLAYER OPERATION
1. Set the Function Switch(CD/OFF/Radio) (#2) to the "CD" position.
2. Open the CD Door (#7). Place an audio CD with its label side upward in the CD compartment and close the
CD Door.
3. After a few seconds, the total number of tracks on the CD will appear in the CD LCD Display (#6) .
4. Press the PLAY/PAUSE Button ( 11#) and the CD will start playing from the first track.
5. Adjust the Volume Control (#3) to obtain the desired sound level from the Speakers (#16) .
6. To suspend playing, press the CD PAUSE Button (#11). The LCD Display will flash. To resume playing, press
the CD PLAY Button again.
7. You can choose to play your favorite track directly by pressing the Skip+/Skip- Button (#15) skip forward or
skip backward. The LCD Display (#6) will indicate the correct track number selected.
8. To repeat playing a particular track, press the REPEAT Button (#12) once.
9. To repeat playing the entire CD , ,, press the REPEAT Button (#12) twice.
10. To stop playing, press the CD STOP Button (#5).
11. When you wish to turn off the CD Player, set the Function Switch(CD/OFF/Radio) (#2) to the "OFF" position.
MP3 PLAYER OPERATION
1. PLAY/PAUSE
Press PLAY/PAUSE button (#11) one time play MP3 and press PLAY/PAUSE button (#11) two times to
suspend.
2. you can choose to play your favorite track directly by pressing the Skip+/Skip-Button (#15) to skip forward
or skip backward.The LCD Display (#6) Will indicate the correct track number selected.
3. To repeat playing a particular track, press the REPEAT Button (#12) once. The Repeat Indicator in the CD
Track Display will flash.
4. To repeat playing the entire CD , , , press the REPEAT Button (#12) twice.
5. To stop playing, press the STOP Button (#5)
CD/MP3 PROGRAMMED PLAY
This function allows the tracks to be played in a programmed sequence.
1. Under CD stop condition, press the PROG+10 Button
(#4) . The LCD Display (#6) will display “01” and the FM
Stereo Indicator will flash.
2. Press the Skip+/Skip- Button (#15) to select the song to be programmed.
