11 GB
• Never cover reflectors or lights.
• Do not modify the bike basket or mounting
bracket.
• Mount the bike basket according to mounting
instructions and ensure fasteners are securely
attached before each ride.
Assembly
Fig. A:
Unfold bike basket (1).
Fig. B:
Bend the brace (2) and insert into the basket so
that the hook and loop fasteners on the brace
and on the basket meet.
Fig. C:
Slide support into the left and right straps.
Fig. D:
Place handlebar bracket (3) over handlebar and
feed the rope (7) into the left bracket notch from
the bottom, wrap around the handlebar, feed
through the right notch and pull tight.
Now secure the rope with 1x screw (4a) using
the Allen key (8).
Fig. E:
Install the handlebar bracket with 2x washers
(5) and 2x screws (4b) on both ends, using the
Allen key (8) to tighten.
Fig. F:
When mounting the handlebar bracket, be sure
the screw is positioned correctly.
Insert the screws into the handlebar bracket as
shown with the tick mark.
Fig. G:
Slide bike basket onto handlebar bracket until it
locks in.
Fig. H:
To remove the bike basket press down on the red
button and slide off basket in the direction of the
arrow.
Congratulations on purchasing this high-
quality product. Be sure to familiarise
yourself with the assembly instructions prior
to use. Please take the time to carefully read
through the following instructions for use and
safety notes. Only use the product as described
and for the intended use. Please retain these
instructions for future reference and ensure that
they are passed on to any third party.
Scope of delivery
1 x Bike basket (1)
1 x Brace (2)
1 x Handlebar bracket (3)
1 x Screw M5x25mm (4a)
2 x Screw M5x30mm (4b)
2 x Washer 5mm (5)
2 x Pads, thin (6)
1 x Rope (7)
1 x Allen key (8)
1 x Instructions for use
Technical Data
Max. load: 5kg
Safety notes
• CAUTION: Do not use to transport bulk foods.
• Only mount the bike basket to the handlebar
as described in the instructions.
• The handlebar bracket is designed for
handlebars with a diameter of 23mm (thick
pad, preinstalled) and 25.4mm (thin pad,
included).
• Ensure the bike basket is securely attached
prior to each ride.
• Never load the bike basket with loads
heavier than 5kg.
• Never exceed the bike’s approved total
weight. The bike’s handling performance will
change depending on the load inside the
bike basket.
• Never bend or pinch Bowden cables.
