8 GB
A
1
b
2
c
2
F
3
E
3
5
4b
G
3
D3 D4
D1
D2
D
7
4a
3
D5
Congratulations on purchasing this high-
quality product. Be sure to familiarise
yourself with the assembly instructions prior
to use. Please take the time to carefully read
through the following assembly instructions and
safety notes. Only use the product as described
and for the intended use. Please retain these
instructions for future reference and ensure that
they are passed on to any third party.
contents
(1) Bike basket
(2) Brace
(3) Handlebar bracket
(4a) 1 x Screw M5x25mm
(4b) 2 x Screw M5x30mm
(5) 2 x Washer 5mm
(6) 2 x Pads, thin
(7) Rope
(8) Allen key
(9) Instructions for use
technical specifications
Max. load: 5kg
safety Precautions
• CAUTION: Do not use to transport bulk foods.
• Only mount the bike basket to the handlebar
as described in the instructions.
• The handlebar bracket is designed for
handlebars with a diameter of 23mm (thick
pad, preinstalled) and 25.4mm (thin pad,
included).
• Ensure the bike basket is securely attached
prior to each ride.
• Never load the bike basket with loads
heavier than 5kg.
• Never exceed the bike’s approved total
weight. The bike’s handling performance will
change depending on the load inside the
bike basket.
• Never bend or pinch Bowden cables.
• Never cover reflectors or lights.
• Do not modify the bike basket or mounting
bracket.
