4

GB

4. Items supplied

1 Christmas street (consisting of 5 houses)
1 House lighting with 4 wired LED modules
2 Type AA, LR6 batteries (each 1.5 V)
1 Set of operating instructions

5. Inserting the

batteries

WARNING! Risk of material damage!
Be sure to observe the correct polarity when
inserting the batteries.

1. Figure A: push the battery compart-

ment lid5 in the direction of the arrow
and open the battery compartment lid
by lifting it up.

2. Figure B: insert the 2 type AA, LR6

batteries (each 1.5 V), as depicted.

3. Lower the battery compartment lid5

and push it in the direction of the arrow
as far as it will go.

6. Installation and

operation

1. Insert the LED modules3 into the recess-

es at the back of the houses4. The ca-
bles must point downwards when doing
this. Carefully press together the sides of
the LED modules, but do not exert too
much pressure on the back of the hous-
es4.

2. Plug the connecting plug2 into the con-

necting socket6 of the house1 with
battery compartment. The groove of the
connecting plug must point downwards
when doing this.

3. Switch on the lighting of the Christmas

street by sliding the on/off switch7 on
ON.
The lighting is switched off by sliding
the switch on OFF.

NOTE: the house1 with the battery compart-
ment can also be operated on its own.

7. Cleaning and

storage

WARNING! Risk of material damage!
Remove the batteries if the device is not go-
ing to be used for a longer period of time.
Otherwise, the batteries may leak and dam-
age the article.

• Clean the article with a brush or feather

duster.

• Press the sides of the LED module3 to-

gether carefully and pull them out of the
housing4. Carefully pull the connecting
plug2 out of the connecting socket6.
Please pull on the plug, not on the cable.

• Choose a storage space which does not

expose the article to excess heat or
dampness.

8. Disposal

The symbol showing a wheel-
ie bin crossed through indi-
cates that the product
requires separate refuse col-
lection in the European Un-
ion. This applies to the product and all
accessories marked with this symbol. Prod-
ucts identified with this symbol may not be
discarded with normal household waste, but
must be taken to a collection point for recy-
cling electric and electronic appliances. Re-
cycling helps to reduce the consumption of
raw materials and protect the environment.

__RU101272_B3.book Seite 4 Freitag, 20. Juni 2014 3:56 15
