A3 Laminator
1. Intended use
This laminator is intended exclusively for use in priva-
te households and for the hot and cold lamination
of documents printed on paper or cardboard.
Additionally, the documents can be trimmed.
It is NOT intended for use with any other materials.
It is also NOT intended for commercial or industrial
applications.
The warranty does not provide compensation for
damage caused by improper use of the appliance!
2. Items supplied
1x Laminator with pluggable cutter attachment
8x DIN A3 size Laminating pouches for hot lamina-
tion (80 microns)
1x Operating instructions
3. Appliance description
q Foil guide rails (rear)
w Cutting rail
e Cutting head
r Foil format restraint
t Slot for manual foil feed
y Indicator lamp "Ready"
u ON/OFF Indicator lamp
i Selector switch for hot and cold lamination
(HOT and COLD)
o Anti-blockage switch and foil thickness switch
a Foil slot (front)
s Document support
d Cutter attachment
4. Technical Data
Rated voltage: 220 - 240 V~ 50 Hz
Current consumption: 1.4 A
Power consumption: 300 W
Lamination speed:
Foil width: max. 320 mm
Foil thickness hot lamination: max. 125 Mikron
Foil thickness cold lamination: max. 200 Mikron
Protection class: II/
Cutting capacity of the cutter attachment d :
max. 3 Sheets of 80g/m 2 or a laminated document
(80 micron).
Sheet size 80 Micron 125 Micron
A4 approx. 52 s approx. 70 s
A3 approx. 75 s approx. 105 s
