Livarno Z31065A-BS/ Z31065B-BS User Manual
Page 2
J
In the event of damage,
repairs or other problems
with the lamp, please
contact the Service Centre
or an electrician.
J
Before installation, switch
off the electrical circuit at the
circuit breaker box or remove
the fuse from the fuse box.
J
Never let the lamp come
into contact with water or
other liquids.
J
Never open or insert
anything into electrical
fittings or equipment. Doing
this sort of thing can lead to
a serious danger to life from
electric shock.
J
Before assembly, ensure that
the mains voltage available
corresponds to the operating
voltage necessary of the light
(Z31065A-BS: 100–
240 V~; Z31065B-BS: 230–
240 V~).
J
Use Model Z31065A-BS
only with the supplied
plug-in mains adapter.
Failure to comply with this
instruction will invalidate
any warranty claims.
To avoid danger
of fire and injury
J
RISK OF INJURY! Check
every bulb and lampshade
for damage immediately
upon unpacking. Do not fit
the light if the bulbs and / or
lampshades are faulty. If
they are, contact the service
point for a replacement.
DANGER
OF ELECTRIC SHOCK!
DANGER OF DAMAGE
TO PROPERTY! DANGER
OF INJURY! Ensure that
GB/IE
GB/IE
GB/IE
GB/IE
GB/IE
GB/IE
GB/IE
components bearing this symbol.
Products marked in this way may
not be disposed of along with
normal domestic waste but have
to be handed in at a recycling
collection point for electrical and
electronic appliances. Recycling
helps to reduce the consumption
of raw materials and to ease the
burden on the environment.
EMC
j
CAUTION! First ensure
that all the under-unit lights
are connected by an
extension lead
8
before
you insert the mains lead
into the mains socket.
Q
Maintenance and
Cleaning
Allow the lamp to cool down
completely.
DANGER
TO LIFE FROM ELECTRIC
SHOCK! Before carrying
out any tasks on the lamp,
switch off the electrical
circuit at the circuit breaker
box or remove the fuse from
the fuse box.
j
CAUTION! Do not use
solvents, petrol etc.
DANGER
TO LIFE FROM ELECTRIC
SHOCK! For reasons of
electrical safety, the light
must never be cleaned with
water or other fluids or be
immersed in water. When
cleaning, only use a dry,
lint-free cloth.
Q
Disposal
The packaging and
ancillary packing
consist entirely of
environmentally-friendly
materials. They can be disposed
of at your local recycling facility.
The symbol of the
wheelie bin with the
line through it means
that, in the European Union, the
product has to be disposed of in
a separate refuse collection. This
applies to the product and to all
j
Mark the two mounting
holes a distance of approx.
432 mm apart.
j
Now drill the mounting
holes (ø approx. 6 mm,
depth approx. 30 mm).
CAUTION! Make sure that
you do not damage any
electrical cables during this
operation.
j
Insert the supplied dowels
10
into the drilled holes. Insert
the supplied screws
11
into
the dowels and tighten them.
Let them project a distance
of about 1.3 mm from the
wall or mounting surface.
j
Attach the light to the
screws
11
using the
appropriate wall mounting
holes
5
.
j
Plug the connection cable
with mains plug
7
into the
socket for the connection
cable
2
.
j
Plug the connection cable
with mains plug
7
into the
mains socket. Your light is
now ready for operation.
Extensions
j
Note: Ensure that no more
than 3 under-unit lights of
the same type (Z31065B-BS)
are connected together in
series. Install each
additional light at a
distance of approx. 15 cm
as described.
j
Remove the protective cap
4
by unscrewing the screw.
Connect the two under-unit
lights to the socket
2
using
the extension lead
8
. Then
you only need one connec-
tion lead
7
for the power
supply.
not suitable for every type
of wall. If installing on
concrete walls, for example,
you will need to use special
dowels and screws.
Information on suitable
installation material can be
obtained from specialist
stores.
j
First screw only one of the
mounting rails
9
in the pre-
drilled positions with the
supplied screws
12
.
j
Place the under cabinet light
flat on the mounting surface
and push it onto the
mounting rail
9
up to the
stop in the slot
6
(see Fig.
C).
j
Push the second mounting
rail
9
into the slot
6
on
the under cabinet light so
that the drilled hole is visible.
Tighten the screw in this
position (see Fig. D).
j
Now push the under cabinet
light a little to the right. Both
mounting rails
9
should
now be firmly positioned
(see Fig. E). Check that the
under cabinet light is fitted
securely.
j
Plug the connecting lead
7
into the socket
2
.
j
Plug the mains plug of the
connecting lead
7
into a
socket. Your under cabinet
light is now ready for
operation.
Q
Mounting model
Z31065B-BS on a
wall
j
Measure up the wall or
mounting surface for drilling
the holes. Use a spirit level
to improve accuracy.
a spirit level to position it
correctly.
j
Mark the position of the drill
holes
1
in the under
cabinet light.
j
Mark the two mounting
holes at a distance of
362 mm apart.
j
Drill the holes, ø approx.
2 mm, depth approx. 10 mm.
j
Position the under cabinet
light according to the drilled
holes and tighten the
screws
6
.
j
Plug the connecting lead
5
into the socket
4
.
j
Plug the mains plug of the
connecting lead
5
into a
socket. Your under cabinet
light is now ready for
operation.
Note: Only use the lamp
with the mains adapter it
was delivered with (LPS03-
120-0250-3). Damage due
to use of a different adapter
is not covered by the
guarantee.
Q
Installing light
Z31065B-BS
j
Use the mounting rails
9
(see also Fig. B) and the
screws
12
for under cabinet
installation.
j
Measure the space for
installation of the light. Use a
spirit level to position it
correctly.
Mark where you wish to
drill and pre-drill the holes.
j
Mark the distance of 533 mm
for the two fixing holes. Drill
the holes: ø approx. 2 mm,
approx. 10 mm deep.
Note: The supplied screws
are for standard installation
under wall cabinets and are
you do not strike electrical
cables, gas or water pipes
when you are drilling into
the wall. If necessary, check
the wall using a suitable
detector before you drill.
J
RISK OF
INJURY FROM
BURNS! Ensure
the lamp has been switched
off and allowed to cool before
you touch it. In this way you
will avoid the danger of burns.
Bulbs give off a lot of heat
around the top of the lamp.
J
Do not use this light for
dimmers or electronic
switches. It is not suitable
for these purposes.
Working safely
J
Install the lamp so that it is
protected from moisture,
wind and dirt.
J
Make careful preparations
for the assembly and take
sufficient time. Clearly lay
out all components and any
additional tools or materials
that might be required so
that they are readily to hand.
J
Remain alert at all times and
always watch what you are
doing. Always proceed with
caution and do not
assemble the lamp if you
cannot concentrate or feel
unwell.
Q
Installation and
operation
Q
Installing light
Z31065A-BS
j
Measure the space for
installation of the light. Use
6
IAN 94495
OWIM GmbH & Co. KG
Stiftsbergstraße 1
D-74167 Neckarsulm
Model no.: Z31065A-BS /
Z31065B-BS
Version: 10 / 2013
