6 GB/IE
Always check the appliance and the mains
supply for damage before connecting it to the
mains. Please do not use this device if you find
that it is damaged in any way.
Do not expose the light to humidity. Otherwise
it may be damaged.
This light is for indoor use only.
Avoid the danger of death
from electric shock!
Before using the product, ensure that the
available mains voltage corresponds with the
operating voltage (100–240 V∼ 50 / 60 Hz)
required for the mains supply (model no.
WSC12-2AB).
Always check the product and lead for
damage before connecting it to the mains.
Dispose of the light if the power cord is
damaged.
Never allow the appliance to come into contact
with water or other liquids.
Protect the mains connection cable from sharp
edges, mechanical loads and hot surfaces.
The product is suited for operation using the in-
cluded power adapter (model no.
WSC12-2AB) only.
Please note that the power adapter consumes
a small amount of power as long as it is
plugged in even when the product is not in op-
eration. Disconnect the power adapter from the
outlet to fully turn it off.
Caution!
Risk of burns!
0.3 m
FIRE HAZARD! Fit the light so that
it is at least 0.3 m away from the
material to be illuminated. Fire can
result from the development of too much heat.
Do not allow any objects to cover the light. Fire
can result from the development of too much
heat.
Start-up
Mounting the light
Note: Installation should be carried out by two
persons.
Note: Installation is virtually identical for both
models and only differs in the first installation step
(installing the lamp shade for model
106339-14-01-BS).
Remove the clear plastic clip 18 to the end of
the lower support tube (with cable) 17 before
mounting.
Model 106339-14-01-BS only:
Using the screwdriver 2 , first remove all metal
screws 1 from the ceiling uplight 4 and
attach the lamp shade 3 using these metal
screws (Fig. A).
Screw the lower support tube (with cable) 17
into the centre piece 19 . Screw in slowly and
be sure not to damage the cable (Fig. B).
Screw the lower support tube (without cable) 9
into the centre piece (Fig. B).
Carefully guide the cable and the two lower
support tubes through the metal cover 11 , the
stand 12 and the mounting plate 16 (Fig. C).
A lock washer 15 and a locknut 14 are located
on the lower support tube (with cable). Attach
the lower support tube to the stand using the
locknut and lock washer. Also attach the lower
support tube (without cable)
9 to the stand
using the included locknut and lock washer
(Fig. C).
Connect the mains supply 10 to the connection
cable (Fig. D).
Plug the mains supply into an easy to access
outlet to be able to quickly unplug the mains
supply.
Your light is now ready for operation.
