Livarno Z31858-BS/ Z31410B-BS User Manual
Page 2
OWIM GmbH & Co. KG
Stiftsbergstraße 1
D-74167 Neckarsulm
Model-No.: Z31858-BS/
Z31410B-BS
Version: 11 / 2014
Last Information Update:
10 / 2014 · Ident no.: Z31858-
BS/Z31410B-BS102014-6
GB/IE
GB/IE
GB/IE
GB/IE
normal domestic waste but have
to be handed in at a recycling
collection point for electrical and
electronic appliances. Recycling
helps to reduce the consumption
of raw materials and to ease the
burden on the environment.
Warranty
The device has been manufac-
tured to strict quality guidelines
and meticulously examined be-
fore delivery. In the event of
product defects you have legal
rights against the retailer of this
product. Your legal rights are
not limited in any way by our
warranty detailed below.
The warranty for this device is 3
years from the date of purchase.
Should this device show any
fault in materials or manufacture
within three years from the date
of purchase, we will repair or
replace it - at our choice - free
of charge to you.
The warranty period begins on
the date of purchase. Please
keep the original sales receipt in
a safe location. This document is
required as your proof of pur-
chase. This warranty becomes
void if the device has been
damaged or improperly used or
maintained.
The warranty applies to faults in
material or manufacture. This
warranty does not cover prod-
uct parts subject to normal
wear, thus possibly considered
consumables (e.g. batteries) or
for damage to fragile parts, e.g.
switches, rechargeable batteries
or glass parts.
Q
Operation
j
Press the ON / OFF switch
1
to turn the light on / off.
NOTE: Model Z31410B-
BS has a rotatable shade
(approx. 140°) for direct or
indirect lighting.
Q
Maintenance and
Cleaning
Allow the lamp to cool down
completely.
DANGER
TO LIFE FROM ELECTRIC
SHOCK! Before carrying out
any tasks on the lamp, switch off
the lamp and disconnect the
plug from the mains socket.
DANGER
TO LIFE FROM ELECTRIC
SHOCK! For reasons of electri-
cal safety, the light must never be
cleaned with water or other flu-
ids or be immersed in water.
When cleaning, only use a dry,
lint-free cloth.
Q
Disposal
The packaging and
ancillary packing
consist entirely of en-
vironmentally-friendly materials.
They can be disposed of at your
local recycling facility.
The symbol of the
wheelie bin with the
line through it means
that, in the European Union, the
product has to be disposed of in
a separate refuse collection. This
applies to the product and to all
components bearing this symbol.
Products marked in this way may
not be disposed of along with
j
Now drill the mounting
holes (ø approx. 6 mm,
depth approx. 30 mm).
CAUTION! Make sure that
you do not damage any
electrical cables during this
operation.
j
Insert the supplied dowels
8
into the drilled holes.
j
Position the mounting bracket
7
according to the dowel
8
, then insert the supplied
screws
9
into the dowels
8
and tighten them.
j
Attach the light to the secured
mounting brackets
7
.
j
Plug the connection cable
with mains plug
5
into the
socket for the connection
cable
2
.
j
Plug the connection cable
with mains plug
5
into the
mains socket. Your light is
now ready for operation.
Extensions (See Fig. A)
j
Note: Ensure that no more
than 3 under-unit lights of
the same type (for model
Z31410B-BS only) are con-
nected together in series.
Connect only same type of
lamp only. Don’t connect
other type of lamp with this
lamp.
j
Remove the protective cap
4
. Connect the two under-
unit lights to the socket
2
using the extension connec-
tor
6
. Then you only need
one connection lead
5
for
the power supply.
j
CAUTION! First ensure
that all the under-unit lights
are connected by an exten-
sion connector
6
before
you insert the mains lead
into the mains socket.
Working safely
J
Install the lamp so that it is
protected from moisture
and dirt.
Q
Installation and
operation
Q
Installing light
j
Use the mounting brackets
7
and the screws
10
for
under cabinet installation.
j
Mark the distance of
200 mm for the two fixing
holes. Drill the holes: ø ap-
prox. 2 mm, approx. 15 mm
deep.
j
Position the mounting brack-
ets
7
according to the
drilled holes and tighten the
screws
10
.
j
Attach the light to the secured
mounting brackets
7
.
j
Plug the connection cable
with mains plug
5
into the
socket for the connection
cable
2
.
j
Plug the connection cable
with mains plug
5
into the
mains socket. Your light is
now ready for operation.
Q
Mounting on a wall
j
Use the mounting brackets
7
, screws
9
and dowels
8
for wall mounting instal-
lation.
j
Measure up the wall or
mounting surface for drilling
the holes. Use a spirit level
to improve accuracy.
j
Mark the two mounting
holes a distance of approx.
200 mm apart.
