26 GB
Disposal / Warranty and Service Preparation / Installation / Cleaning
Familiarise yourself with all the instructions and
diagrams in this manual, as well as with the
light itself, before you install it.
Before installation ensure that the circuit, to
which the light will be connected, is not ener-
gised. To do so, remove the fuse or switch off
the circuit breaker in the fuse box (Position 0)
(Fig. A).
Use the voltage tester to verify the de-ener-
gised status.
Installation
Unscrew the cover 2 and glass 3 from the
connection housing 4 by loosening the
screws 1 counter-clockwise.
Use the holes in the connection housing 4 ,
which are intended for the screws, to mark the
drill holes. Open these (if not already open)
with a sharp object (e.g. screwdriver).
Now drill the fixing holes (ø 6 mm, depth ap-
prox. 40 mm). Be careful not to damage the
supply line.
Now insert the wall plugs 6 into the drill holes.
Feed the power cord (external) 8 through the
cable guide with membrane 7 .
Open these (if not already open) with a sharp
object (e.g. screwdriver).
Fasten the connection housing 4 using
included screws 5 and wall plugs 6 .
Feed the power cord (external) 8 through the
cable guide 9 .
Connect the power cord (external) 8 to the
lamp socket.
Also ensure that the colour connection of the
wires is correct when connecting (L or 2 =
black or brown, N or 1 = blue or white).
Now connect the earth wire (3 = green-yellow)
to the marked earth terminal .
Check for correct fitting.
Use a dry, lint-free cloth when inserting the
lamp 10 .
Carefully insert the lamp 10 into the socket
and tighten clockwise.
Secure the cover 2 with glass 3 to the con-
nection housing 4 by tightening the screws
1 clockwise.
Your lamp is now ready for use.
Reinsert the fuse or switch the circuit breaker
back on (Fig. G).
Replacing lamps
CAUTION! RISK OF ELECTRIC SHOCK!
To replace the bulb, first of all disconnect the
light from the mains circuit. To do so, remove
the fuse or switch off the circuit breaker in the
fuse box (position 0) (Fig. A).
Allow the light to cool off completely.
Use a dry, lint-free cloth to replace a bulb.
Unscrew the cover
2 and glass 3 from the
connection housing 4 by loosening the
screws 1 counter-clockwise.
Turn the defective lamp 10 counter-clockwise
out of the socket.
Insert a new lamp 10 into the socket and se-
cure clock-wise.
Check for correct fitting.
Secure the cover
2 with glass 3 to the con-
nection housing 4 by tightening the screws
1 clockwise.
Reinsert the fuse or switch the circuit breaker
back on (Fig. G).
Cleaning
CAUTION! RISK OF ELECTRIC SHOCK!
Disconnect the light from the mains circuit
before cleaning. To do so, remove the fuse or
switch off the circuit breaker in the fuse box
(position 0) (Fig. A).
Only use a dry, lint-free cloth for cleaning. Do
not use solvents, spirit or similar substances.
They could damage the light.
Allow the light to cool off completely.
Reinsert the fuse or switch the circuit breaker
back on (Fig. G).
