Livarno 10270B/ JL-T009 - Manual (Page 8)

8 GB
In low light the light will automatically switch
on, and automatically switch off in normal
ambient light.
Replacing the rechargeable
battery
The batteries should be replaced every 12 months
to ensure optimum performance.
Remove the lampshade 1 from the lamp
body 3 .
Rotate the solar cell housing 2 counter-
clockwise out of the lampshade 1 .
Switch off the light using the ON/OFF switch 6
by setting the switch to the „OFF“ position.
Remove the fixing screws 7 using a small
cross-tip screwdriver.
Replace the old rechargeable battery 9 with
a new one. Be sure to insert the batteries in the
correct direction. This is shown inside the bat-
tery compartment
8 . Use only rechargeable
batteries of the recommended type (see
„Technical Data“).
Tighten the retaining screws 7 with a small
cross-tip screwdriver. Slide the ON/OFF switch
6 to the „ON“ position.
Reattach the solar cell housing 2 to the lamp
shade 1 . Then assemble the remaining parts
of the lamp.
Charging
Please note, the solar garden light must be
switched on when the battery is charging. The bat-
tery charging period using the solar cell depends
on the intensity of the sunlight and the angle inci-
dence of the light on the solar cell. Place the solar
cell as perpendicular as possible to the angle of
light incidence. In this way you will receive the
highest light levels.
Maintenance and Cleaning
The LEDs cannot be replaced. The solar lamp is
maintenance-free, except for any necessary
change of battery.
Clean the solar lamp regularly with a dry,
non-fluffing cloth. Use a slightly moist cloth to
remove any stubborn dirt.
Troubleshooting
Note: the device contains sensitive electronic com-
ponents. For this reason it is possible that it can be
disrupted by radio transmitting equipment in the
immediate vicinity. If you notice that the device is
malfunctioning, remove any sources of interference
from the area of the device.
Note: Electrostatic discharge can cause malfunc-
tions. In the event of such malfunctions briefly
remove and reinsert the rechargeable batteries.
Fault Cause Solution
The light will
not switch on
even though
the sun shone
on the lamp all
day. Artificial sour-
ces of light,
e.g. street
lighting, inter-
fere with the
lamp. Place the light in
a location whe-
re it will not be
affected by
other light
sources.
The light does
not come on or
comes on only
briefly. The recharge-
able battery
is broken or
there was not
enough day-
light. Replace the
rechargeable
battery or mount
the lamp in a
place where it
can receive
more sunlight.
