 How to use
Note: The light has a motion sensor that reacts to
temperature changes. The sensor works best at an
ambient temperature below 20 °C. A moving object
at a temperature close to the ambient temperature
is only detected with great difficulty.
Note: The controls are at the front of the lamp,
above the motion sensor
8 (Fig. A).
The range of the motion sensor 8 is approx.
6 - 8 m (+ / - 2 m) if the lamp is installed at a
height of 1.80 to 2.50 m (Fig. G). It has a roughly
100° detection radius (Fig. H)
 Regulating the sensitivity
of the light

Turn the control to regulate the light sensitivity 7
clockwise to increase the sensitivity of the light.

Turn the control to regulate the light sensitivity 7
anti-clockwise to decrease the sensitivity of the
light.
Note: When the lamp is switched on, the light
sensitivity sensor is switched off so that even despite
the brightness from the light movements can still be
detected.
 Regulating the duration
of the illumination
The amount of time the light stays on can be set to
a value between approx. 5 and 240 - 300 seconds.

Turn the control to regulate the duration of the
illumination
6 clockwise to increase the dura-
tion of the illumination.

Turn the control to regulate the duration of the
illumination 6 anti-clockwise to decrease the
duration of the illumination.
Note: After the motion detector has switched the light
on, the light will stay on for the set period of time. If
during this period a new movement is detected, the
time the light stays on for will be extended by the set
period of time.
 Replacing the illuminant

Make sure that the lamp is dead, i.e. not live.
To do so, remove the fuse or move the switch
of the fuse in your sub-distribution to “0”.

The lamp can get very hot when in use. If nec-
essary, allow the lamp to cool down for about
15 minutes.

Remove the lamp cover 1 . To do so, remove
the cross-head screws 3 that connect the
lamp cover 1 to the lamp body 5 .

Remove the illuminant 2 from the base.

Insert a new illuminant with a suitable base
and of an appropriate wattage (see section on
“Technical data”).

Screw the lamp cover 1 back onto the lamp
body 5 .

Switch the electrical power back on.
 Cleaning and Care

Switch the lamp off before starting to clean it.
To do so, remove the fuse or move the switch
of the fuse to “0“.

Let the lamp cool down for at least 15 minutes
before cleaning it.

Never use water or any other fluid to clean the
lamp. Do not immerse the lamp in water.

Only use a dry, lint-free cloth to clean the product.

If the product is more severely soiled, you may
have to use a slightly damp cloth and a mild
detergent.

Do not use any solvents, petrol or similar. This
would cause damage to the device.
How to use / Cleaning and Care
