34 GB
Installation
CAUTION! RISK OF INJURY!
Consult the drill manufacturer‘s operating
manual before you use your drill.
Installing the floor
light in soil or wooden
substrates
1. Choose a suitable location for the
floor light.
2. First excavate a hole with a depth
to match the height of the light in
the ground or drill a correspondingly
sized hole in a wooden substrate.
Note: Bear in mind that the decora-
tive collar
2
must be placed on top of
the substrate surface later (see Fig. G).
3. Switch the light on by pressing the
ON / OFF switch
9
.
Note: Please bear in mind that the
light will only switch itself on or off
under twilight conditions automati-
cally if the light is switched on.
4. Insert the light into the substrate.
Your light is now ready for operation.
Installing the floor light
in concrete substrates
Note: A quantity of mixed concrete is
required for this stage of the installation.
Follow the manufacturer’s instructions.
1. Choose a suitable location for the
floor light.
2.
Drill
a
hole in the concrete substrate.
Note: Ensure that the depth of the
hole corresponds with the depth of the
floor insert
11
with concrete socket
including the floor light. Bear in mind
that the decorative collar
2
must be
placed on top of the substrate sur-
face later (see Fig. G).
3. Pour a little mixed concrete into the
predrilled hole.
