INSTALLATION AND USE MANUAL Glossary
GAUDI’ pag. 34
Glossary Technical service – all rights reserved by mcz spa
Reproduction prohibited
VITE PH-AB 3,9X9,5 SCREW PH-AB 3.9X9.5
VITE AUTOPERF.4,2X16 SELF-TAPPING SCREW 4.2X16
PAGE 9 PAGE 9
PROFILO COPRIBORDO EDGE-COVER PROFILE
PAVIMENTO FLOOR
LATO CARICAMENTO LOADING SIDE
LATO SERVIZIO SERVICE SIDE
PAGE 10 PAGE 10
LATO CARICAMENTO FORMA PUROB95 LOADING SIDE FORMA PURO B95
LATO SERVIZIO FORMA PUROB95 SERVICE SIDE FORMA PURO B95
PAGE 11 PAGE 11
SPALLA TERMOCAMINO FIREPLACE STOVE SIDE
PAGE 12/13/14/15 PAGE 12/13/14/15
LATO CARICAMENTO FORMA PUROB95 LOADING SIDE FORMA PURO B95
LATO SERVIZIO FORMA PUROB95 SERVICE SIDE FORMA PURO B95
PAGE 16 PAGE 16
LATO CARICAMENTO FORMA PUROB95 LOADING SIDE FORMA PURO B95
SPALLA RIVESTIMENTO A VISTA VISIBLE CLADDING SIDE
SUPPORTO NON A VISTA NON-VISIBLE SUPPORT
LATO SERVIZIO FORMA PUROB95 SERVICE SIDE FORMA PURO B95
PAGE 17 PAGE 17
ALLINEATI
ALIGNED
PAGE 18/19 PAGE 18/19
LATO CARICAMENTO FORMA PUROB95 LOADING SIDE FORMA PURO B95
LATO SERVIZIO FORMA PUROB95 SERVICE SIDE FORMA PURO B95
PAGE 20 PAGE 20
A FILO
FLUSH
PAGE 21/22/23 PAGE 21/22/23
LATO CARICAMENTO FORMA PUROB95 LOADING SIDE FORMA PURO B95
LATO SERVIZIO FORMA PUROB95 SERVICE SIDE FORMA PURO B95
PAGE 24 PAGE 24
SPALLA TERMOCAMINO
FIREPLACE STOVE SIDE
BASE VANO
COMPARTMENT BASE
PAGE 25 PAGE 25
