DP800A Quick Guide
13
Rear Panel
The rear panels of the various models of DP800A series are as shown in the figures
below. In this section, DP831A (as shown in Figure 6 and Table 1) is taken as an
example to introduce the rear panels of DP800A series.
Figure 6 DP831A Rear Pannel
Figure 7 DP811A Rear Panel
11
10 9 8 7
1 2 3 4 5 6
