8.0 Machine Parts List
Drawing No. Item ID Item Description Qty. Needed
1 SP-3-ST-BLKGRAN Black Granite 3-Gallon Solution Tank 1.00
2 SP-3-R-GRYGRAN Grey Granite 3-Gallon Recovery Tank 1.00
3 10-0383 6-32 x 1/4” Phil Pan Screw 6.00
4 10-0400-D Latch for Sniper 1.00
5 10-0412 C-Channel for Spotter Handle 2.00
6 10-0414 Rivet for Spotter Handle 4.00
7 10-0384 .125 Thick Nylon Washer 4.00
8 10-0385 .06 Thick Nylon Washer 4.00
9 10-0074 Flat Washer #8 SAE 5.00
10 10-0216 Allen Head Screw for Backpack 4.00
11 10-0379 8-32 x 3/8” Screw 4.00
12 10-0405 1-1/2” PVC SCH40 Slip Thread 1.00
13 10-0302-A Hatch Cover Gasket for Spotter 1.00
14 10-0416-A 1-1/2” Black ABS Stand Pipe 0.60
15 10-0304 Spotter Cap and Float Assembly 1.00
16 10-0419 Screw for Spotter Hatch 6.00
17 SP-3-H-BLK 3-Gallon Spotter Black Handle 1.00
18 10-0406 Nylon Barb 90 1/8” NPT 1/4” 2.00
19 80-0017-2 Bulk Head fitting for Spotter 1.00
20 10-0403 1/8” Brass Female Coupler 1.00
21 10-0402 1/8” Male QD 1.00
22 10-0434 Threaded Hose for Spotter 2.50
23 10-0407 1/8” Strait Nylon Barb NPT 4.00
24 10-0845-2 1/8” Strainer for Spotter 1.00
25 10-0300 55 psi Pump for Spotter 1.00
26 10-0301 L Bracket for Spotter 1.00
27 10-0435 Oetiker Clamp 4.00
28 10-0303 Roller Blade Wheel for Spotter 2.00
29 10-0387 5/16” x 1” Spotter Wheel Bolt 2.00
30 10-0022 Shoulder and Waist Belt Screw 1.00
31 10-0017 Deflector Screw 1.00
32 10-1028 Bottom Base Plate for Spotter 1.00
33 10-0492 Screw for Plates on Spotter 2.00
34 10-0014 Motor Screw 2.00
35 10-0380 10-32 x 3/8” Screw 2.00
36 10-1024 Motor Mount Plate for Spotter 1.00
37 10-0354 3-Gallon Spotter Motor 1.00
38 10-0386 Stamped Motor Screen 1.00
39 10-1030 Spotter Motor Gasket 1.00
40 10-0027-A Strain Relief Nut 1.00
41 10-1026 Switch Plate for 3-Gallon w/ Heat 1.00
42 10-0027 Pigtail Strain Relief 1.00
43 10-0448 20-Foot Spotter Cord 1.00
44 10-0025 On/Off Switch 2.00
45 10-0400-C Keeper Latch for Spotter 1.00
