PC-TFT-35VX
Purdy Electronics Corporation • 720 Palomar Avenue • Sunnyvale, CA 94085
6
Tel: 408.523.8200 • Fax: 408.733.1287 • [email protected]
7/20/07
www.purdyelectronics.com
I/O Board
Connector
Description
Power (J6)
(- + +5V center pin
AV (J7)
RCA jack (signal center pin)
S-Video (J8)
Optional
VGA (J2)
DB15 (PC Input)
Interface (J1)
14 wire Interface
Keyboard
Name
Location
Function
Power
SW1
On/Off
Lamp
LED
Indicator
Sensor
IC1
Optional
Enter
SW2
Select
Down
SW3
Decrement
Up
SW4
Increment
Menu
SW5
Brightness, Contrast, Color, Tint, Sharpness
