DLD-350FD Projector Specifications
Imaging Devices
0.7-inch D-ILA (1920X1080) x 3; >90% Aperture Ratio
Brightness
1600 ANSI Lumens (typical) / 1000 ANSI Lumens (minimum)
Resolution
3840 x 2160 V4K™ [e-shift] 4K Resolution
Contrast Ratio
150,000:1
Uniformity
Greater than 80%
Aperture
16 Steps (Lens Aperture)
Gamma Control
Std 2.2 Gamma and 3 Custom Gamma presets
Color Management
7-Axis adjustable CMS
HDMI Input-Supported Formats
1920x1080 60p/50p (Dual Input Capability)
Low Latency Mode
1080p60/50
Latency
25ms w/1080p60 Input
Color Bit Depth
10-bit Input via HDMI 1.4b, 10-bit display
I/O Terminals
2 x HDMI v1.4b (locking HDMI connectors); LAN: RJ45 x 1; RS-232C: D-Sub 9 pin (male) x 1; Wired Remote (Mini) x 1
Remote Control
RS-232C/LAN Fully featured control protocol Wired/IR Remote Control
Lens
1.45-2.78:1 Zoom Lens (Remote Zoom and Focus), ± 80% Vertical Offset, ± 34% Horizontal
Offset
Light Source
Laser/Phosphor: 125 Steps Power Setting (25%-100%) Class II laser
Light source Life
20,000h (typical @ Max Power) / 40,000h (typical @ Low Power with Auto Intensity)
Power Requirement
AC 100V-240V, 50/60Hz
Power Consumption
290 Watts Maximum, 5W Standby
Noise Level (0-26°C, 32-79°F)
~42dB (A) at 39.4”/1m (3.3ft)
Operating Environment
Temperature range: 5°C-35°C
Humidity: 20%-80% (non-condensing)
Operating Altitude
Recommended <2000 meters for safe operation
Installation Orientation
Angle free
Dimensions ( W x H x D )
19.5 x 8.8 x 22.5 in., 496 x 224 x 572 mm
Weight
38.1lbs, (17.3kg)
Supplied Accessories
Power Cord x1 (US, EU); IR Remote Control
Approvals
Safety
North America CSA C22.2 No.60950-1-07(Amd1:2011), UL60950-1-2011 2nd edition
Europe IEC60950-1:2005(2nd)+Amd1:2009+Amd2:2013 EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
EMI
North America FCC part 15 Class A(US), ICES-003 Issue 5 Class A(CAN),
Europe EN61000-3-2:2006+A1:2009+A2:2009, EN61000-3-3:2013, EN55022:2010(Class A), EN55024:2010
Australia EN55022:2010/AC2011 Class A
Environmental
Common RoHS
North America Proposition 65 (US)
Europe WEEE New Battery directive
External Video Processor
Wolf Cinema ProScaler MK III
(Refer to separate ProScaler Specifications)
All features, designs and specifications are subject to change without notice.
V4K and E-VariScope are trademarks of Wolf Cinema.
D-ILA is a registered trademark of JVC KENWOOD Corporation. BLU-Escent is a trademark of JVC KENWOOD Corporation.
HDMI is a registered trademark of HDMI Licensing LLC.
All other brand or product names may be trademarks and/or registered trademarks of their respective owners. Any rights
not expressly granted herein are reserved.
Copyright © 2015 Wolf Cinema. All Rights Reserved.
