PSR-E353 MIDI Reference 3
MIDI Data Format
NOTE:
1 By default (factory settings) the instrument ordinarily functions as a
16-channel multi-timbral tone generator, and incoming data does not
affect the panel voices or panel settings. However, the MIDI messages
listed below do affect the panel voices, auto accompaniment, and
songs.
• MIDI Master Tuning
• System exclusive messages for changing the Reverb Type and Cho-
rus Type.
2 Messages for these control change numbers cannot be transmitted
from the instrument itself. However, they may be transmitted when
playing the accompaniment, song or using the Harmony effect.
3 Exclusive
<GM System ON>
F0H, 7EH, 7FH, 09H, 01H, F7H
• This message automatically restores all default settings for the
instrument, with the exception of MIDI Master Tuning.
<MIDI Master Volume>
F0H, 7FH, 7FH, 04H, 01H, ll, mm, F7H
• This message allows the volume of all channels to be changed
simultaneously (Universal System Exclusive).
• The values of “mm” is used for MIDI Master Volume. (Values for
“ll” are ignored.)
<MIDI Master Tuning>
F0H, 43H, 1nH, 27H, 30H, 00H, 00H, mm, ll, cc, F7H
• This message simultaneously changes the tuning value of all chan-
nels.
• The values of “mm” and “ll” are used for MIDI Master Tuning.
• The default value of “mm” and “ll” are 08H and 00H, respectively.
Any values can be used for “n” and “cc”.
<Reverb Type>
F0H, 43H, 1nH, 4CH, 02H, 01H, 00H, mmH, llH, F7H
• mm : Reverb Type MSB
• ll : Reverb Type LSB
Refer to the Effect Map (page 3) for details.
<Chorus Type>
F0H, 43H, 1nH, 4CH, 02H, 01H, 20H, mmH, llH, F7H
• mm : Chorus Type MSB
• ll : Chorus Type LSB
Refer to the Effect Map (page 3) for details.
4 When the accompaniment is started, an FAH message is transmitted.
When accompaniment is stopped, an FCH message is transmitted.
When the clock is set to External, both FAH (accompaniment start)
and FCH (accompaniment stop) are recognized.
5 Local ON/OFF
<Local ON> Bn, 7A, 7F
<Local OFF> Bn, 7A, 00
Value for “n” is ignored.
Effect map
* When a Type LSB value is received that corresponds to no effect type, a value corresponding to the effect type (coming the closest to the specified
value) is automatically set.
* The numbers in parentheses in front of the Effect Type names correspond to the number indicated in the display.
REVERB
CHORUS
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000 No Effect
001 (01)Hall1 (02)Hall2 (03)Hall3
002 Room (04)Room1 (05)Room2
003 Stage (06)Stage1 (07)Stage2
004 Plate (08)Plate1 (09)Plate2
005...127 No Effect
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000...063 No Effect
064 No Effect
065 (3)Chorus3 (2)Chorus2
066 Celeste (1)Chorus1
067 Flanger (4)Flanger1 (5)Flanger2
068...127 No Effect
