Features – NEC MultiSync EA241F 23.8" 16:9 IPS Monitor (No Stand) User Manual
Page 26
English-24
Features
3-side Narrow Bezel:
Stylish appearance and less distance between adjacent screens in a multi-monitor setup.
Fully Ergonomic Stand:
Provides viewing flexibility with 150 mm height adjustment, -5 ~ 35-degree tilt, 340-degree swivel, with
cable management and a small footprint. The ability to pivot to either side can minimize width between adjacent bezels in multi-
monitor installations. The bottom of the monitor cabinet can touch the stand base for lower positioning requirements.
ErgoDesign Features:
Enhance human ergonomics to improve the working environment, protect the health of the user and
save money. The ergonomic features include a fully articulating stand, OSD controls that can rotate 90/180/270 degrees for
quick and easy image adjustment, and lower emissions.
VESA Standard Mounting Interface:
Connects the monitor to any VESA standard third party mounting arm or bracket.
Various Signal Interfaces:
This model has various interfaces. Fore more detail, please see
Plug and Play:
The Microsoft
®
solution with the Windows
®
operating system facilitates setup and installation by allowing the
monitor to send its capabilities (such as screen size and resolutions supported) directly to the computer, automatically optimizing
display performance.
USB Hub 3.1 Gen.1:
The USB hub adds flexibility to your computing by providing easy access to USB SuperSpeed data
transfer and charging via USB. For more details, please see
Hardware Calibration:
Adjusts brightness, colors and gamma curve for your preference with software and color sensor.
USB Monitor Control:
Allows you to adjust each item through application software by connecting a USB cable.
Color Control Systems:
Adjusts the colors on the screen and allows customization of the color accuracy of the monitor to a
variety of standards.
Human/Ambient Sensors:
Controls screen brightness according to user presence and ambient light status for less power
consumption.
Response Improve (RESPONSE IMPROVE):
Improves gray to gray response.
Intelligent Power Manager System:
Provides innovative power-saving methods that allow the monitor to shift to a lower-
power mode when on but not it use, reducing emissions and lowering the cost of operating the monitor by reducing its power
consumption.
ControlSync:
Provides control and settings synchronization for up to five MultiSync EA series displays, as well as individual
control of any single monitor in the ControlSync chain, from a single master monitor (see
Individual Adjust (INDIVIDUAL ADJUST):
A designated main monitor can adjust an individual sub monitor(s) by the OSD. It is
good for multi-setting monitors which are positioned far from the user.
Customize Setting (CUSTOMIZE SETTING):
Allows to store the current settings and recover stored settings.
Low Blue Light:
Low Blue Light function substantially reduces blue light and helps to alleviate eye-strain (see
Flicker Free:
Special backlight system reduces flicker for less eyestrain.
NaViSet Administrator 2 Software:
Offers an expanded and intuitive graphical interface, allowing adjustments of the OSD
display settings from a network PC.
Environmental Impact (EA231WU):
Annual typical maximum operating carbon footprint of this monitor (world-wide average) is
approximately 41.8 kg (calculated by: rated wattage x 8 hours per day x 5 days a week x 45 weeks per year x Power-to-Carbon
conversion factor - conversion factor is based on OECD publication of global CO2 emissions 2008 Edition). This monitor has a
manufacturing carbon footprint of approximately 51.4 kg.
Environmental Impact (EA241F):
Annual typical maximum operating carbon footprint of this monitor (world-wide average) is
approximately 42.7 kg (calculated by: rated wattage x 8 hours per day x 5 days a week x 45 weeks per year x Power-to-Carbon
conversion factor - conversion factor is based on OECD publication of global CO2 emissions 2008 Edition). This monitor has a
manufacturing carbon footprint of approximately 52.6 kg.
Note:
The manufacturing and operating carbon footprints are calculated by a unique algorithm developed exclusively by NEC
for its monitors and are accurate at the time of printing. NEC reserves the right to publish updated carbon footprint values.
