Getting started
- 9 -
∫ Front
1 Disc tray ( > 12)
2 USB port ( DC 5 V 500 mA) ( > 12)
This port supports USB 2.0 High Speed.
3 POWER LED
The LED lights when the unit is turned on,
and flashes when error occurs. (
> 25)
4 Remote control signal sensor
Distance: Within approx. 7 m (23 feet)
Angle: Approx. 20
e up and down, 30 e left and
right
5 Open or close the disc tray ( > 12)
6 Standby/on switch ( Í /I ) ( > 11)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
still consumes a small amount of power.
Rear panel terminals ( > 10)
CAUTION
Do not place objects in front of the unit. The disc tray may collide with objects when it is opened, and
this may cause malfunction.
≥ When inserting a media item, ensure that it is facing the correct way, which is the right side facing up.
≥ If you connect a Panasonic product with a USB connection cable, the setup screen may be displayed
on the connected equipment. For details, refer to the instructions for the connected equipment.
The symbols on this product (including the accessories) represent the following.
6 5
1
2 3 4
AC
DC
Class II equipment (The construction
of the product is double-insulated.)
