Invacare 4000 - Manual (Page 5)

5
Wheel Lock
Assembly
(STEP 15)
Rear Wheel
(STEP 13)
Plug Button
(STEP 8)
Locknut
(STEP 9)
Pivot Arm
Spacer
(STEPS 12,13)
Axle Lug
(STEP 13)
Locknut
(STEP 14)
2-inch Mounting
Screw (STEP 11)
Pivot Arm Assembly
(STEPS 8,9,12,13)
WheelChair
Frame
3/4-inch
Mounting
Screw
(STEP 15)
Heavy
Washer
(STEP 15)
Axle Mounting
Screw
(STEPS 13,14)
Tube Clamp
Bushing
Strap/Stud
Assembly
ThinWasher
Locknut
(STEPS 9-11)
Back Tube
(STEP 10)
Mounting
Screw
(STEPS 2,6,)
Locknut
(STEPS 2,6)
Locking Rod
(STEPS 2-6)
Anti-Rattle
(STEPS 3,5,6)
Recliner Tube
(STEPS 1,5,)
BackTube
Mounting
Bracket
(STEPS
2,6,)
Bolt and
Locknut
(STEP 1)
Attendant Operated
Wheel Lock
(STEPS 1,4,5)
Locknut
(STEPS 2,6)
Recliner Tube
(STEPS 1,5,6)
FIGURE 4 -CONVERTING FROM ATTENDANT OPERATED WHEEL LOCKS
STEPS 1-6
STEP 7
Locknut Wheelchair Frame
Rear Wheel
Axle Mounting
Screw
Spacer
STEPS 8-16
