For your future construction needs, consider the
entire series of FastHome
™
Enclosures and Modules.
FastHome
™
Enclosures
From a centralized location,
Fast Media Home Network
Systems enclosures fully inte-
grate, manage and distribute
broadband and multimedia serv-
ices on a flexible, customizable
and upgradeable platform.
Constructed of 18-gauge cold
rolled steel for strength and
protection against interference,
FastHome
™
enclosures mount
on a wall (surface mount) or
between 16˝ center wall studs
(flush mount).
FastHome
™
Modules
High-quality FastHome
™
modules
by Steren provide secure, reliable
connections for voice, video,
data and audio applications.
Each module is housed in a
sturdy 18-gauge cold rolled steel
construction for excellent RFI
shielding. The system is expand-
able by adding multiple modules.
550-100
Small Surface Mount Enclosure
7˝(W) x 11˝(H) x 3
5
/
16
˝(D)
550-105
Large Surface Mount Enclosure
14
9
/
16
˝(W) x 19˝(H) x 4
5
/
16
˝(D)
550-200
Small Flush Mount Enclosure
14
3
/
8
˝(W) x 19˝(H) x 3
1
/
2
˝(D)
550-205
Medium Flush Mount Enclosure
14
3
/
8
˝(W) x 32˝(H) x 3
1
/
2
˝(D)
550-210
Large Flush Mount Enclosure
14
3
/
8
˝(W) x 44˝(H) x 3
1
/
2
˝(D)
550-010
Fast Media Telephone/TV Hub Module
6
1
/
2
˝(W) x 4
3
/
4
˝(H) x 1˝(D)
550-020
Fast Media Telephone Hub Module
6
1
/
2
˝(W) x 2
7
/
8
˝(H) x 1˝(D)
550-030
Fast Media Data Hub Module
6
1
/
2
˝(W) x 2
7
/
8
˝(H) x 1˝(D)
550-040
Fast Media TV
Combiner/Splitter Module
6
1
/
2
˝(W) x 2
7
/
8
˝(H) x 1˝(D)
550-050
Fast Media Audio Splitter Module
6
1
/
2
˝(W) x 2
7
/
8
˝(H) x 1˝(D)
550-060
Fast Media Ethernet Switch Module
6
1
/
2
˝(W) x 2
3
/
4
˝(H) x 1˝(D)
550-070
Fast Media Power Module
6
1
/
2
˝(W) x 2
5
/
8
˝(H) x 1˝(D)
550-080
Fast Media RF Modulator Module
6
1
/
2
˝(W) x 3˝(H) x 2
3
/
8
˝(D)
