English 13
Specifications
Specifications subject to change without notice.
Audio Section
Max Power Output ............................................................................................................800 W × 1
Rated Power Output
Normal (4 Ω) (20 Hz – 20 kHz, 0.08 % THD) ....................................................................150 W × 2
Normal (4 Ω) (DIN : 45324 , +B = 14.4V) ........................................................................150 W × 2
Normal (2 Ω) (1 kHz, 0.8 % THD) ....................................................................................230 W × 2
Bridged (4 Ω) (1 kHz, 0.8 % THD) ....................................................................................460 W × 1
Frequency Response (+0, –3 dB) ..................................................................................5 Hz – 50 kHz
Sensitivity (rated output) (MAX.) ................................................................................................0.2 V
Sensitivity (rated output) (MIN.) ................................................................................................5.0 V
Signal to Noise Ratio................................................................................................................100 dB
Input Impedance........................................................................................................................10 kΩ
Low Pass Filter Frequency (18 dB/oct.) ............................................................50 – 200 Hz (variable)
High Pass Filter Frequency (12 dB/oct.) ..................................................................................150 Hz
Bass Boost Circuit (90 Hz) KAC-7251 ............................................................OFF / +6 / +9 / +12 dB
Bass Boost Circuit (90 Hz) KAC-7201 ............................................................................OFF / +12 dB
General
Operating Voltage ..................................................................................14.4 V (11 – 16 V allowable)
Current Consumption (4 Ω, 10 % THD) ......................................................................................43 A
Dimensions (W × H × D) ......................................................................................285 Ч 57 Ч 305 mm
.................................................................................................................... 11-1/4 Ч 2-1/4 Ч 12 inch
Weight ......................................................................................................................3.32 kg (7.3 lbs)
