RECOMMENDED OPTIONS
Vantage ® 400
www.lincolnelectric.com [7]
Drive Roll and Guide Tube Kit
(for LN-25 PRO)
For .035" and .045" (0.9-1.1 mm) solid
steel wire.
Order KP1696-1
LN-23P Wire Feeder
Portable CV unit for Innershield pipe
welding. Includes drive rolls and guide
tubes. Requires K2393-1 or -2 Input
Cable Assembly and Magnum
®
Innershield ® Gun.
Order K316L-2
Input Cable Assembly for LN-23P
8-socket to 14-pin control cable with
lugged electrode cable for K316L-2
LN-23P Wire Feeder.
Order:
K2393-1 25 ft (7.6 m)
K2393-2 75 ft (22.9 m)
Magnum ® 350 Innershield ® Gun
(for LN-23P)
Rated 350 amps, 60% duty cycle. For
.068"-5/64" (1.7-2.0 mm) Innershield
®
wire and includes reduced speed
switch.
Order K345-10
Magnum ® SG Spool Gun
Hand held semiautomatic wire feeder.
Requires SG Control Module and Input
Cable.
Order K487-25
SG Control Module
The interface between the power
source and the spool gun. Provides
control of the wire speed and gas flow.
For use with a spool gun.
Order K488
Input Cable
(For SG Control Module)
For Lincoln engine power sources with
14-pin MS-type connection, separate
115V NEMA receptacles and output
stud connections.
Order K691-10
PLASMA CUTTING
Pro-Cut ® 55
Cuts metal using the AC generator
power from the engine-driven welder.
Accepts 3-phase or 1-phase input
power. Requires the K1816-1 Full KVA
adapter kit, if connected for 1-phase
input power.
Order K1580-1
Full-KVA Adapter Kit (1-Phase)
Provides convenient connection of
Lincoln Electric equipment having a
240V AC 1-phase plug (NEMA 6-50P)
to the full-KVA receptacle on Lincoln
engine-driven welders.
Order K1816-1
Hand Amptrol ®
Provides 25 ft. (7.6 m) of remote
current control for TIG welding.
(6-pin plug connection). Velcro
straps secure torch.
Order K963-3 (one size fits all
Pro-Torch
® TIG Torches)
Precision TIG ® 225
Ready-Pak ® Pkg.
For AC TIG Welding with square
wave performance, use the AC gen-
erator of the engine-driven welder
to supply the power (Full rated
output may not be available). Easy
setup. Includes torch, Foot Amptrol
®
and Gas Regulator & Hose. Requires
the K1816-1 Full KVA Adapter Kit.
Order K2535-1
Invertec ® V205-T AC/DC
One-Pak ® Package
For AC TIG welding with square
wave performance, use the AC
generator of the engine-driven
welder to supply the power. Easy
setup. Includes torch, parts kit,
regulator and hose kit, Twist-Mate
™
torch adapter, work cable with
Twist-Mate end and foot Amptrol
® .
Requires K1816-1 Full-KVA Adapter
Kit.
Order K2350-2
Full - KVA Adapter Kit (1-Phase)
Provides convenient connection of
Lincoln Electric equipment having a
240V AC 1-phase plug (NEMA 6-
50P) to the full-KVA receptacle on
Lincoln engine-driven welders.
Order K1816-1
WIRE FEEDER OPTIONS
LN-25 PRO Wire Feeder
Portable CC/CV unit for flux-cored
and MIG welding with MAXTRAC
®
wire drive system. Includes gas sole-
noid and internal contactor
Order K2613-1
Magnum ® 350 Innershield Gun
(for LN-25 PRO)
For self-shielded wire with 15 ft.
(4.5 m) cable. For .062"-3/32"
(1.6-2.4 mm) wire.
Order K126-2
Drive Roll and Guide Tube Kit
(for LN-25 PRO)
For cored or solid steel wire.
Order KP1697-068
for .068"-.072" (1.8 mm)
KP1697-5/64
for 5/64" (2.0 mm)
Magnum ® 300 MIG Gun
For .035"-.045" (0.9-1.2 mm) gas-
shielded wire with 15 ft. (4.5 m)
cable.
LN-25 PRO Order:
K1802-1 (Includes Connector Kit)
