JBW75W Type
SHAPES AND DIMENSIONS
TERMINAL DESIGNATION
Connector made by
Power supply side
connector
Cable Side
Option
Part No.
Housing
Terminal
Set
4EU20G085
Japan Solderless Terminal Co., Ltd.
Input Connector(CP1)VH Series
B3P5-VH-B
VHR-5N
SVH-21T-P1.1
Output Connector(CP2)VH Series
B6P-VH-B
VHR-6N
SVH-21T-P1.1
9max.
9max.
(45.9)
222
5
5
(4.5)
212±0.5
55
5
5
45±0.5
( 25.9
)
29
3max.
1.6
5
3
1
CP1
1
6
CP2
Area for spacer(ø
6max.)
Solder Side
(
2 Places)
Ground pattern area(ø
6max.)
Solder Side
(
2 Places)
4-ø3.5
( 33
)
( 43.2
)
( 50.9
)
(5.3)
Dimensions in mm
±1mm : without specified dimensions
CP2
P1
P2
P3
P4
P5
P6
–
+
CP1
5
3
1
CP1
1
2
3
4
5
6
CP2
· Japan Solderless Terminal Co., Ltd.
VH Series B6P-VH-B
P1
P3
N
L
P5
· Japan Solderless Terminal Co., Ltd.
VH Series B3P5-VH-B
