J8436A-A
X2-SR 10GB Module
850nm, 300m, MMF, SC RoHS6
_______________________________________________________
Approved Optics, Inc. www.ApprovedOptics.com Page 2 of 8
Average Receive Optical Power RxP max 1.5 dBm
Exceeding any one of these values may permanently destroy the device.
Electrical Characteristics
Recommended Operating Conditions
Parameter Symbol
Values Unit
min. typ. max.
Operating Case Temperature
TC
0 70 °C
Transponder Total Power Consumption P 2.2 W
Supply Voltage +5.0 V VCC5 4.75 5 5.25 V
Supply Current +5.0 V
ICC5
157 190 mA
Supply Voltage +3.3 V VCC3 3.14 3.3 3.47 V
Supply Current +3.3 V ICC3 55 72 mA
Supply Voltage APS VCC aps 1.152 1.2 1.248 V
Supply Current APS ICC aps 830 850 mA
.
Electrical DC Characteristics
(VCC5= 4.75 V to 5.25 V, VCC3= 3.14 V to 3.47 V, VCCaps= 1.152 V to 1.248 V, TC= 0°C to 70°C)
Parameter Symbol
Values Unit
min. typ. max.
1.2 V CMOS (1.8 V CMOS Compatible1)) I/O DC Characteristics (PRTAD; LASI; RESET;
TX_ONOFF)
External Pull-up Resistor for Open
Drain
Rpullup
10 22 kΩ
Output High Voltage2)
Voh 1 V
Output Low Voltage2)
Vol
0.15 V
Input High Voltage Vih
0.8
4
1.5 V
Input Low Voltage Vil 0.36 V
Input Pull-down Current3)
Ipd 20 120 μA
XAUI I/O DC Characteristics (TXLANE[0..3]; RXLANE[0..3])
Differential Input Amplitude (pk-pk) 4)
Vin_xaui 200 2500 mV
Differential Output Amplitude (pk-pk) 4) Vout_xaui 800 1600 mV
MDIO I/O DC Characteristics (MDIO; MDC)
Output Low Voltage5)
VOL –0.3 0.2 V
Output Low Current IOL 20 mA
