Littelfuse SMDJ-HR Series - Manual (Page 6)

Transient Voltage Suppression Diodes
60
TVS Diode Arrays
(SPA ™ Family of Products)
©2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 11/18/13
Surface Mount – 3000W > SMDJ-HR series
SMDJ-HR Series
Part Numbering System
Packaging
Part number
Component
Package
Quantity
Packaging
Option
Packaging
Specification
SMDJxxxXX-HR DO-214AB 500 Tape & Reel – 16mm/7” tape EIA STD RS-481
Part Marking System
VOLTAGE
BI-DIRECTIONAL
5% VOLTAGE TOLERANCE
SERIES
SMDJ -HR XXX C A
HIGH RELIABILITY
Tape and Reel Specification
0.63
(16.0)
0.315
(8.0)
0.157
(4.0)
0.65
(16.4)
0.80 (20.2)
Arbor Hole Dia.
7.0 (187)
Dimensions are in inches
(and millimeters).
Direction of Feed
0.059 DIA
(1.5)
Cover tape
Cathode
6
F
XXX
YMXXX
Marking Code
Trace Code Marking
Y:Year Code
M: Month Code
XXX: Lot Code
Littelfuse Logo
Cathode Band
(for Uni-directional products only)
