Asus U53Jc User Manual
Page 13
Notebook PC User Manual
13
1
2
3
6
Power (DC) Input
Air Vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
Ensure that paper, books, clothing, cables, or other objects
do not block any of the air vents or else overheating may
occur.
Wireless Switch
Enables or disables the built-in wireless LAN and
Bluetooth (selected models). When enabled, the wireless
status indicator will light. Windows software settings are
necessary before use.
Flash Memory Slot
HDMI
HDMI Port
HDMI (High-Definition Multimedia Interface) is an
uncompressed all-digital audio/video interface between
any audio/video source, such as a set-top box, DVD player,
and A/V receiver and an audio and/or video monitor, such
as a digital television (DTV). Supports standard, enhanced,
or high-definition video, plus multi-channel digital audio
on a single cable. It transmits all ATSC HDTV standards and
supports 8-channel digital audio, with bandwidth to spare
to accommodate future enhancements or requirements.
USB Port (2.0)
USB Port (3.0) (on selected models)
USB Port (2.0) (on selected models)
Headphone Output Jack
Microphone Input Jack
Display (Monitor) Output
5
4
8
7
9
10
