A-1
PRO 100
A-1 INSTALLATION
Fuse or
Output Mode Input Voltage Breaker Size Input Amps Power Cord Extension Cord
RATED 115V/60Hz 20 Amp 20 15 Amp, 125V,
Three Conductor
Three Prong Plug
#14 AWG
(NEMA Type 5-15P)
(2.1 mm 2 ) or Larger
Up to 25 Ft. (7.6 mm)
CSA 115V/60Hz 15 Amp 12 15 Amp, 125V, Three Conductor
Three Prong Plug #12 AWG
(NEMA Type 5-15P) (3.3 mm2) or Larger
Up to 50 Ft. (15.2 mm)
TECHNICAL SPECIFICATIONS – PRO 100
INPUT – SINGLE PHASE ONLY
RATED OUTPUT
OUTPUT
RECOMMENDED INPUT CABLE AND FUSE SIZES
Height Width Depth Weight
12.0 in 9.75 in 16.5 in 47 Ibs
305 mm 248 mm 419 mm 21.4 kg
PHYSICAL DIMENSIONS
Standard Voltage/Frequency Input Current
115V/60Hz 20 Amps - Rated Output
115V/60Hz 15 Amps - CSA Rated output
Duty Cycle Amps Volts at Rated Amperes
20% Duty Cycle 88 18
20% Duty Cycle – CSA Rated Output 62 20
Welding Current Range Maximum Open Circuit Voltage Wire Speed Range
Rated DC Output: 30 - 88 amps 32 50 - 300 IPM
CSA Rated DC Output: 30 - 62 amps (1.3 - 7.6 m/min)
