Motif Sketch™ Manual Rev. C Copyright (c) 2013 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length
6.29 inches (16 cm)
Width 2.78 inches (7.5 cm)
Height 3.54 inches (9 cm)
Weight 2.87 lbs (1.3 kg)
Power
Operating Voltage
100-260VAC, 50-60 Hertz
Fuse 2A 250V
Power Consumption 21W, .26A
Power Factor .48
Light Source
LED
7x 3-watt TRI-color LEDs, 100,000 hours.
Optical
Beam Angle
25 degrees
Luminous Intensity
Lux/meter
Red Green Blue All
1m 1,480 1,840 1,900 4,940
2m 410 520 530 1,300
Thermal
Max. Operating Temp.
104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 3-channel
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes Standalone, Master/Slave
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover
malfunction caused by damage to LED’s.
