1
A D D I T I O N A L
W A R N I N G S
I N S T A L L A T I O N
I N F O R M A T I O N
The installation of this appliance must be in accordance with all local codes, or in the
absence of local codes:
• Canadian installation must conform to the current national standards, which at this time
are CAN / CGA-B149.1/2-Natural Gas / Propane installation code.
Drawing A
Minimum clearance to adjacent combustible materials:
• 76 cm (30˝ ) from furthest protruding edge on side of barbecue.
• 76 cm (30˝ ) from furthest protruding edge on back of barbecue.
See Drawing A
• Always keep the area around this barbecue clean and clear of any and all combustible
materials such as gasoline or other inflammable liquids, paper or oily rags.
• Do not operate this barbecue under any overhanging or unprotected construction.
• Remember this barbecue is for outdoor use only and is not for use on any boat or
recreational vehicle.
• Use this barbecue outdoors in a well-ventilated area and at least
3 m (10’) from any dwelling or other building.
• Do not use in garages, or any other enclosed area.
• Do not leave your barbecue unattended while in operation.
• Do not obstruct the flow of combustion and ventilation air to the barbecue.
• Do not use while under the influence of drugs or alcohol.
• Do not store any spare L.P. (propane) cylinders, full or empty,
under or near your barbecue.
• Do not allow children or pets to play anywhere near the barbecue.
U S E O F L P G A S C Y L I N D E R
Self-contained
Propane Gas System
The self-contained (propane) gas system barbecue is designed to be used with only a 9.1 kg
(20 lb) propane cylinder equipped with a type-1 cylinder valve. This barbecue cannot be
connected to an existing #510 P.O.L. type valve cylinder (which has left-handed threads).
Do not connect to a propane gas cylinder exceeding 9.1kg capacity or use a cylinder
with any other type of cylinder valve connection device.
The Type-1 valve can easily be recognized by the large external thread on the outside of the
valve. Older existing valves do not have this outer external thread. Any attempt to connect
a regulator to any connector other than the mating Type-1 connector (which comes with a
large, black coupling nut such as the #510 P.O.L.) could result in fires, injuries or property
damage, and could reduce the effectiveness of the important safety features built into the
Type-1 system. Also connecting the #510 P.O.L. fitting to the cylinder will negate the flow
control and the temperature shut-off features built into the new Type-1 connection system.
• The cylinder should not exceed 472 mm (18 1/2˝ ) in height and
317 mm (12 1/2˝ ) in diameter.
When purchasing a cylinder for your barbecue, it must be constructed and marked
as meeting the specifications of:
• Canada: Transport Canada.
Minimum clearance of 76 cm (30”)
on both sides and back of the barbeque.
