BOTTOM CLIP INSTALLATION

ON BOTH SIDE

SLIDE THE FIXED PANEL

OVER THE WALL JAMB

FASTEN THE THRESHOLD (1)

FASTEN (TEMPORARILY)FIXED PANELS (1)

3

4

5

Step

Step

Step

3A

3B

4A

3C

COVER THE PLIER’S TEETH

BEFOREHAND TO AVOID

SCRATCHING THE ALUMINIUM PARTS.
