11

INSTALLATION MANUAL

2

2f.

2g.

Unscrew the rear side of the 4 hinges as illustrated.

14

*Handle showed is model (Q)

2f

2g

Fasten the front side and one of the rear side component of the hinges to the panel as illustrated.

Use the provided hex. Key.
