INSTRUCTION MANUAL

PARTS LISTING

ITEM

PARTS

QTY

1

SUPPORT BAR

1

2

WALL JAMB

1

3a

SIDE PANEL

1

3b

EXPANDER

1

3c

GASKET

1

4

ALUMINUM “U” CHANNEL

1

5

HINGE

2

6

LEVELING BLOCKS

2

7

BOTTOM DOOR GASKET

1

8

DOOR PANEL

1

9

SIDE PANEL GASKET

1

1

2

3b

3a

3c

4

5

6

7

8

9

HINGE

HINGE
